製品詳細
起源の場所: 中国
ブランド名: Brans
モデル番号: WLSM-132
ドキュメント: WLSM-132 High Accuracy Load...NS.pdf
支払及び船積みの言葉
最小注文数量: 1台のパソコン
受渡し時間: 一週間
支払条件: T/T
供給の能力: 800個/月
容量: |
30g/50g/100g/300g/500g/1kg/2kg |
複合エラー: |
≤0.005%FS |
非線形性: |
≤0.005%FS |
再現性: |
≤0.005%FS |
定格出力: |
1.0mV/V |
ゼロバランス: |
±0.05mV/V |
絶縁抵抗: |
千万MΩ/100VDC |
材料: |
アルミニウム合金 |
安全な過負荷: |
150%F.S. |
保護クラス: |
IP66 (カスタマイズ可能) |
作戦温度。: |
-30~80°C |
ケーブルサイズ: |
Ф3.2x4000mm (カスタマイズ可能) |
容量: |
30g/50g/100g/300g/500g/1kg/2kg |
複合エラー: |
≤0.005%FS |
非線形性: |
≤0.005%FS |
再現性: |
≤0.005%FS |
定格出力: |
1.0mV/V |
ゼロバランス: |
±0.05mV/V |
絶縁抵抗: |
千万MΩ/100VDC |
材料: |
アルミニウム合金 |
安全な過負荷: |
150%F.S. |
保護クラス: |
IP66 (カスタマイズ可能) |
作戦温度。: |
-30~80°C |
ケーブルサイズ: |
Ф3.2x4000mm (カスタマイズ可能) |
Features & Applications
Specifications
| Capacity | 30g/50g/100g/300g /500g/1kg/2kg |
| Combined Error | ≤0.005%F.S. |
| Non-linearity | ≤0.005%F.S. |
| Repeatability | ≤0.005%F.S. |
| Rated Output | 1.0mV/V |
| Zero Balance | 0.05mV/V |
| Insulation Resistance | ≧5000MΩ/100VDC |
| Recommended Excitation | 2~12VDC |
| Material | Aluminum Alloy |
| Safe Overload | 150%F.S. |
| Protection Class | IP66(Customizable) |
| Operation Temp. | -30~80°C |
| Cable Size | Ф3.2x4000mm(Customizable) |
| Nominal Displacement | <0.05mm |
Dimensions(mm)
Load direction
Wiring code
Shipping & Packaging
To ensure safe arrival at your location, the load cell will be carefully packaged and shipped. The packing process is as follows:
1. The load cell will be placed in a sturdy cardboard box to protect it from external damage during shipping.
2. The box will be filled with foam padding to provide additional cushioning and prevent the load cell from moving during shipping.
3. The load cell will be sealed in a plastic bag to protect it from moisture and other environmental factors.
4. Additional layers of bubble wrap will be provided for additional protection.
5. The carton is securely taped to prevent tampering.
6. A shipping label with your address and product information is attached to the box.
7. The package is shipped using a reliable and trusted freight carrier.
Once the package is shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the delivery address to receive the package to avoid any delays or problems.
